1999-2016 Ford Superduty Rear Differential Carrier - DANA 80 Loaded Trac-Lok 4.10 and Up. Ford OEM F81Z-4026-A, F81Z-4026-AA, F81Z-4026-AB

1999-2016 Ford Superduty Rear Differential Carrier - DANA 80 Loaded Trac-Lok 4.10 and Up.

Ford OEM F81Z-4026-A, F81Z-4026-AA, F81Z-4026-AB

• Part Number: F81Z-4026-A
• Replaces: F81Z-4026-AA, F81Z-4026-AB

• SKU:

  F81Z-4026-A

• Other Names: Differential Assembly
• Description:

  F350. 11.25 ring gear. Locking. F250 pick-up. 11.25 ring gear. F350 super duty. Limited slip. Dual rear wheels.

• Notes:Includes Differential Case, Side Gears And Pinion Gears.
• Applications: F350 SUPER DUTY. 1999-07 SUPER DUTY.
• Replaces:

  F81Z-4026-AA, F81Z-4026-AB

Differential. Carrier.
Differential Carrier. Dual Rear Wheels. Includes: Differential Case, Side Gears and Pinion Gears. Limited Slip Differential. Loaded. Case.

Fits F-250, F-250 Super Duty, F-350 Super Duty

F250 Pick-Up; 11.25 Ring Gear; Locking. F350 Super Duty; Dual Rear Wheels; w/Limited Slip. F350 Super Duty; Limited Slip; Dual Rear Wheels. F350; 11.25 Ring Gear; Locking.

Differential Carrier - Repair or Replace
Your differential may need to be removed and rebuilt for a variety of symptoms including whine or groan noises, clunks or grinding, or excessive leaks.

Specifications & Model Diagram

Brand	Spicer
Axle Model	DANA 80
Vehicle Location	Rear
Invoice	DIFF CASE ASSY
Cover Bolt Quantity	10
Axle Shaft Spline Quantity	35
Differential Case Split	4.10 And Up
Differential Type	Trac-Lok
Carrier Type	Loaded
Axle Spline Diameter (IN)	1.50
Bearings Included	Yes
Ring Gear Bolt Quantity	12
Bolt Thread Size	.562-18
Package Type	EACH
Package Qty	1
Weight	47.4 LB
Harmonization Code	8708500000
Country of Origin	United States
California Proposition 65	WARNING: Cancer — www.p65warnings.ca.gov
