2001-2006 Chevy Silverado 3500 AWD/4WD Automatic Extended Cab Rear Upgraded HD 5” Aluminum Driveshaft

Made to Order 2-5 Days

Made with HD 5” x .125” Tubing and 1410 Series Spicer Solid U-Joints

Overall Length is 89” From Tip of Transfer Case Slip Yoke to Center of Rear U-Joint. 80.625” Center U-Joint to Center U-Joint

Transfer Case slip yoke is 31 Spline with a diameter of 1.615”. Hub (seal) Diameter is 2.201”

Driveshaft is made stock length unless we are told otherwise.

**If truck is lifted must provide new measurements! Measure from Tip of Transfer Case Output Seal to Center U-Joint while truck is in riding position. Email measurement with Order number in subject box to Sales@ECDriveline.com

No Returns or Refunds if stock shaft is order and length is wrong
