Dana Spicer
2020-2023 Jeep Gladiator Rear 2 Piece Steel 1350 Series Driveshaft (stock replacement) with Dana 44 AdvanTEK Rear Differential 10132305
2020-2023 Jeep Gladiator Rear 2 Piece Steel 1350 Series Driveshaft (stock replacement) with Dana 44 AdvanTEK Rear Differential 10132305
Couldn't load pickup availability
Lead time from Dana 4-6 Months
**See 20-22 Gladiator Custom Length HD 2 Piece**
Driveshaft Assembly Kit - Jeep Gladiator JT Dana 44 AdvanTEK - Rear (Dana 10132305)
Now for the Jeep Gladiator, the new 2-piece Spicerá1350 series driveshaft is engineered as a direct bolt-in solution that delivers increased strength. Featuring several upgrades designed for added durability on the trail, this driveshaft includesá3 inch DOM tubing and a unique CV Joint with an additional 5 degrees of angle. Dana gives you everything necessary for a bolt-in solution including a center bearing drop bracket kit designed to accommodate vehicles lifted up to 6.5 inches. Spicer performance driveshafts are built with the innovations that give you the confidence to take on the toughest terrain.
Specifications & Model Diagram
| Brand | Spicer |
| Series | 1350 (M220 / Dana 44 AdvanTEK) |
| Shaft Material | Steel |
| Tube Size (Mm) | 76.2 x 2.1 |
| Tube Size (In) | 3 x .08 |
| Tube Size (MM) | 76.2 x 2.1 |
| Slip (Mm) | 160.000 |
| Tube Size (IN) | 3 x .08 |
| Slip (In) | 6.299 |
| Max Slip (MM) | 160.000 |
| Max Slip (IN) | 6.299 |
| Cl Yoke To Cl Yoke(MM) - COLL. | 1518.920 |
| Cl Yoke To Cl Yoke(IN) - COLL. | 59.800 |
| Tube Length (Mm) | 1587.32 |
| Tube Length (In) | 62.493 |
| CL (Yoke To Bearing) (MM) | 611.800 |
| Phased | N |
| CL (Yoke To Bearing) (IN) | 24.087 |
| Note | Install with Center Bearing Drop Bracket Kit - 10149071 |
| Material | Steel |
| Phased - Degrees | 0 |
| Package Type | EACH |
| Package Qty | 1 |
| Country of Origin | United States |
